| Matière du cadre |
High Performance Carbon |
| Batterie |
800Wh |
| Tailles |
Size Split |
| Réglage de l'angle de chasse |
0.6° |
| cadre |
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
| taille |
Size Split: 27.5: S // 29: M, L, XL |
| moteur |
Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
| Télécommande |
Bosch Mini Remote |
| batterie |
Bosch PowerTube 800 |
| écran |
Bosch Kiox 400C |
| chargeur |
Bosch 4A |
| fourche suspendue |
Fox 36 Float Rhythm GRIP, Tapered, 15x110mm, E-Bike Optimized, 150mm |
| amortisseur |
Fox Float Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever |
| entretoises d’amortisseur |
Front: 30x8mm, Rear: DU-Bushing 12.7mm |
| freins |
Shimano XT BR-M8220, Hydr. Disc Brake (203/203) |
| dérailleur arrière |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Commandes |
Shimano XT SL-M8100-IR, 12-Speed |
| Pédalier |
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T |
| cassette |
Shimano Deore CS-M6100, 10-51T |
| chaîne |
KMC e12 |
| Guide-chaîne |
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
| jeu de direction |
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| Potence |
CUBE Performance Stem E-MTB 35, FPI-Link |
| cintre |
CUBE Rise Trail Bar 35 |
| poignées |
ACID Disrupt |
| roues |
Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready |
| pneu avant |
Conti Kryptotal Front, Enduro Soft, Tubeless Ready, 2.4 |
| pneu arrière |
Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4 |
| selle |
ACID Venec EMTB Trail 140 |
| tige de selle |
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| pédales |
ACID PP MTB |
| couleur |
nebula´n´white |
| poids |
24,4 kg |
| Poids maximum en charge |
160 kg |
